IC Series 3000-watt Inverter Charger
IC-3000-12-PKG
Go Power!'s IC Series 3000-watt Inverter Charger offers more power in the same footprint. An inverter, battery charger and transfer switch in one compact unit. The Go Power! 3000-watt Inverter Charger delivers top features and performance at an economical price. The GP-IC-3000 has a compact footprint that saves space and simplifies installation - there are fewer components and cables to install!
The two 50 amp legs set its performance apart from common 50 amp inverter chargers. The configuration allows users to make full use of a 100 amp shore power service (240V) by passing through up to 12,000 watts of power! It is also compatible with all 30 amp services.
Included in the 600-watt Solar Extreme charging system.
Applications
Buying Options
Overview
Product Overview
Model: GP-IC-3000-12
It is a 3-in-1 system that expertly combines an inverter, battery charger and automatic transfer switch into one powerful and lightweight unit. Included in the 600-watt Solar Extreme charging system.
Features
- 3000 watt pure sine wave inverter; 4800 watt surge (5 seconds)
- High inverter efficiency - >90%
- 125 amp battery converter/charger
- 100 amp automatic transfer switch (50 amps per leg at 120V AC)
- Built-in handles offers easier handling during installation
- Industry standard protection features
- Meets UL 458 with marine supplement
- 3 year warranty
Specifications
Product Specifications
|
Inverter Specifications |
||
|
Output Power (up to 40ºC) |
3000W |
|
|
Surge Power (100 milliseconds) |
6000W |
|
|
Surge Power (5 seconds) |
4800W |
|
|
Peak Output Current |
52A |
|
|
Continuous Output Current |
25A |
|
|
Output Voltage |
115 VAC |
|
|
Output Frequency |
60 Hz ±0.1Hz |
|
|
Output Waveform |
Pure Sine Wave |
|
|
Efficiency (Peak) |
90% |
|
|
DC Input Voltage Range |
9-17 VDC |
|
|
Maximum Continuous DC Input Current |
400 ADC |
|
|
No Load Power Consumption |
Normal Mode:25W, Sleep Mode: <5W |
|
|
AC Connections |
Split Phase In/Dual Out, Dual In/ Dual Out |
|
Transfer Time |
16ms |
|
|
Transfer Relay Rating |
2 legs at 50A each (120V each leg) |
|
Input Voltage Nominal |
120 VAC |
|
|
Input Voltage Range |
80 – 140VAC |
|
|
Input Current |
15A |
|
|
Input Power Factor Correction |
0.97 typical |
|
|
Optimal Efficiency |
>85% |
|
|
Charge Control |
3 stage with manual equalize |
|
|
Output Voltage |
5-16 VDC |
|
|
Output Current |
125ADC |
|
|
Change Temperature Compensation |
Remote Battery Sensor |
|
Temperature |
-20˚C to 40˚C (40˚C – 60˚C output derates) |
|
|
Humidity |
0 to 95% RH non condensing |
|
|
Dimensions (L x W x H) |
13.7” x 12.6” x 8.07” 348 x 320 x 205 mm |
|
|
Net Weight |
49.8 lbs (22.6 kg) |
|
|
Regulatory and Safety Specifications |
UL certified to 458 & 1741 (with Marine Supplement) and to CSA 22.2 No. 107.1-01 FCC Path 15, Class B |
