200-watt Portable Solar Kit
This 200-watt Portable Solar Kit (PSK) folding solar module is ideal for those who don’t want to permanently mount solar to a rooftop or want to supplement a roof top system. This panel, when paired with 200Ah of AGM or 100Ah of Lithium battery power, generates enough charge to keep an RV’s lights, fans, water pumps, and slide outs running for up to 4 days off the grid.
Adjustable folding legs to maximize solar exposure and for compact easy storage. Multiple charging connectivity options. Includes a heavy duty nylon case for storage protection. They also are a great supplemental solar kit to a roof top kit.
*Best paired with 200Ah of AGM Battery Power, or 100Ah Lithium Battery Power.
Applications
Buying Options
Quick Links
200-watt Portable Solar Kit
GP-PSK-200
Applications
Buying Options
Quick Links
Product Overview
Model: GP-PSK-200
The largest Go Power! portable solar kit. Sets up quickly for powerful mobile battery charging RV batteries.
COMPATIBLE WITH
Included with the Portable Solar Kit:
The Portable Solar Kits come with a variety of battery charging options with Anderson-style, quick connectivity.
- 30 amp, single bank, charge controller (GP-PWM-30-SB)
- Battery clamps
- Quick connectors
- Ring terminal connectors
- SAE solar plug adapter
- XLR-style solar plug adapter
- 12′ of UV 12/2 cable
- Heavy-duty, nylon storage case
Other Accessories Sold Separately.
Product Specifications
| GP-PSK-200 | GP-PSK-130 | GP-PSK-90 | |
|---|---|---|---|
| Solar cell type | Monocrystalline | Monocrystalline | Monocrystalline |
| Output power | 200 W | 130 W | 90 W |
| Rated current | 11.4 A | 6.7 A | 4.6 A |
| Rated DC voltage | 17.6 V | 19.7 V | 19.8 V |
| Open-circuit voltage | 21.1 V | 23.8 V | 23.6 V |
| Connectivity | Battery clamps, Quick connectors, Ring terminal connectors, SAE solar plug adapter, XLR-style solar plug adapter |
||
| Solar controller | 30-amp Single Bank | 10 A, PWM, built-in | |
| Frame type | Silver anodized aluminum frame, built-in adjustable folding legs | ||
| Certifications |  |
||
| Rated | IP52 | ||
| Dimensions Closed (H x W x D) | 39 x 26.4 x 5.6 in / 1005 x 670 x 70 mm | 32.5 x 19.9 x 2.8 in / 824 x 503 x 70 mm | 21.7 x 19.9 x 2.5 in / 550 x 505 x 65 mm |
| Dimensions (open) | 39 x 52.8 x 2.8 in / 1005 x 1340 x 70 mm | 32.5 x 39.8 x 1.4 in / 824 x 1006 x 33 mm | 21.7 x 39.8 x 1.3 in / 550 x 1010 x 33 mm |
| Weight | 51 lbs / 23 kg | 33 lbs / 15 kg | 19.8 lbs / 9 kg |
| Warranty | 25 years (module) / 3 years (controller) | ||
|
|
GP-PWM-30-SB |
|
Nominal System Voltage |
12V |
|
Max Solar Array Current |
30A |
|
Battery Voltage Range |
6V — 15.5V |
|
Max. Solar panel input voltage |
28V |
|
Operating Consumption |
6mA |
|
Display Consumption |
15mA |
|
Temp. Compensation |
-13mV/ºF / – 24mV/ºC |
|
Operating Temperature |
– 40 to 185ºF / – 40 to 85ºC |
|
Humidity |
99% N.C. |
|
Dimensions (H x W x D): |
4.25 x 7.48 x 1.38 in; 108 x 190 x 35 mm |
|
Weight |
10.6 oz; 300 g |
|
Maximum Wire Gauge: |
#4 AWG |
|
Warranty |
5 years |
|
Protection |
Battery Reverse Polarity, Solar Array Reverse Polarity, Over temperature, Over Current |
|
Rated |
IP50 |
FAQ & Support
+ - Is this kit waterproof?
This kit is not waterproof or weatherproof. Never leave your Portable Solar Kit unattended, plugged in overnight, or subject to inclement weather.
+ - What is included in this kit?
This kit includes: - 10 amp charge controller (GP-PWM-10-FM) - Battery clamps - Quick connectors - Ring terminal connectors - SAE solar plug adapter - XLR-style solar plug adapter - 12' of UV 12/2 cable - Heavy-duty, nylon storage case
Product Support Resources
Model: GP-PSK-200
The largest Go Power! portable solar kit. Sets up quickly for powerful mobile battery charging RV batteries.
COMPATIBLE WITH
Included with the Portable Solar Kit:
The Portable Solar Kits come with a variety of battery charging options with Anderson-style, quick connectivity.
- 30 amp, single bank, charge controller (GP-PWM-30-SB)
- Battery clamps
- Quick connectors
- Ring terminal connectors
- SAE solar plug adapter
- XLR-style solar plug adapter
- 12′ of UV 12/2 cable
- Heavy-duty, nylon storage case
Other Accessories Sold Separately.
Portable Solar Kit Spec Comparison
| GP-PSK-200 | GP-PSK-130 | GP-PSK-90 | |
|---|---|---|---|
| Solar cell type | Monocrystalline | Monocrystalline | Monocrystalline |
| Output power | 200 W | 130 W | 90 W |
| Rated current | 11.4 A | 6.7 A | 4.6 A |
| Rated DC voltage | 17.6 V | 19.7 V | 19.8 V |
| Open-circuit voltage | 21.1 V | 23.8 V | 23.6 V |
| Connectivity | Battery clamps, Quick connectors, Ring terminal connectors, SAE solar plug adapter, XLR-style solar plug adapter | ||
| Solar controller | 30-amp Single Bank | 10 A, PWM, built-in | |
| Frame type | Silver anodized aluminum frame, built-in adjustable folding legs | ||
| Certifications | |
||
| Rated | IP52 | ||
| Dimensions Closed (H x W x D) | 39 x 26.4 x 5.6 in / 1005 x 670 x 70 mm | 32.5 x 19.9 x 2.8 in / 824 x 503 x 70 mm | 21.7 x 19.9 x 2.5 in / 550 x 505 x 65 mm |
| Dimensions (open) | 39 x 52.8 x 2.8 in / 1005 x 1340 x 70 mm | 32.5 x 39.8 x 1.4 in / 824 x 1006 x 33 mm | 21.7 x 39.8 x 1.3 in / 550 x 1010 x 33 mm |
| Weight | 51 lbs / 23 kg | 33 lbs / 15 kg | 19.8 lbs / 9 kg |
| Warranty | 25 years (module) / 3 years (controller) | ||
Controller Specifications
| GP-PWM-30-SB | |
|
Nominal System Voltage |
12V |
|
Max Solar Array Current |
30A |
|
Battery Voltage Range |
6V — 15.5V |
|
Max. Solar panel input voltage |
28V |
|
Operating Consumption |
6mA |
|
Display Consumption |
15mA |
|
Temp. Compensation |
-13mV/ºF / – 24mV/ºC |
|
Operating Temperature |
– 40 to 185ºF / – 40 to 85ºC |
|
Humidity |
99% N.C. |
|
Dimensions (H x W x D): |
4.25 x 7.48 x 1.38 in; 108 x 190 x 35 mm |
|
Weight |
10.6 oz; 300 g |
|
Maximum Wire Gauge: |
#4 AWG |
|
Warranty |
5 years |
|
Protection |
Battery Reverse Polarity, Solar Array Reverse Polarity, Over temperature, Over Current |
|
Rated |
IP50 |
