Retreat Solar Kit (100 WATTS)
The 100-watt Retreat Solar kit is our most efficient solar charging kit available and is ideal for rooftops where space is limited. The Go Power! Retreat Solar Kit features 100 watts and 5.43 amps of charge power. For extended or full-time traveling, see our Overlander Solar Kit or an AC power system like the Solar Elite.
Go Power!’s 100-Watt Retreat Solar Kit is ideal for RVs or boats with limited roof space.
*Best paired with 200Ah of AGM Battery Power, or 100Ah of Lithium Battery Power.
Applications
Buying Options
Quick Links
Retreat Solar Kit (100 WATTS)
RETREAT
The 100-watt Retreat Solar kit is our most efficient solar charging kit available and is ideal for rooftops where space is limited. The Go Power! Retreat Solar Kit features 100 watts and 5.43 amps of charge power. For extended or full-time traveling, see our Overlander Solar Kit or an AC power system like the Solar Elite.
Go Power!'s 100-Watt Retreat Solar Kit is ideal for RVs or boats with limited roof space. *Best paired with 200Ah of AGM Battery Power, or 100Ah of Lithium Battery Power.Applications
Buying Options
Quick Links
Product Overview
MODEL: RETREAT
Learn how to choose a Solar Kit, select an Expansion Kit for the Retreat or use our Go Power! Calculator to size your system.
Included in Kit:
- 100-watt solar panel (GP-PV-100M)
- 30-amp single-bank, Bluetooth® Solar Controller (GP-SB-PWM-30BT)*
- 25′ of solar output cable - RED (#10)
- 25′ of solar output cable - BLACK (#10)
- Mounting hardware (1 x GP-MH-4-KB)
*If you have the GP-PWM-30-UL controller WITHOUT Bluetooth, please click here for the User Manual and Spec Sheet.
Product Specifications
| Solar cell type | Monocrystalline |
|
Output power
|
100 W
|
|
Rated current
|
5.43 A |
|
Rated DC voltage
|
18.4 V
|
| Open-circuit voltage | 22.6 V |
| Module efficiency | 15.34% |
| Connectivity | Solar Branch Connectors |
| Solar controller | 30 A PWM, multi battery option, 4 stage charging, digital display and flush mount |
| Frame type | Silver / black anodized aluminum frame |
| Certifications | CE |
| Dimensions | 47.09 x 21.46 x 1.38 in / 1196 x 545 x 35 mm |
|
Weight
|
17.6 lbs / 8 kg
|
|
Warranty
|
25 years (module) / 5 years (controller)
|
| OVERLANDER | RETREAT | ECO 80 Watt | |
|---|---|---|---|
| Output power | 200 W | 100 W | 80 W |
| Solar cell | Monocrystalline | Monocrystalline | Polycrystalline |
| Installation | Roof mount | Roof mount | Roof mount |
| Solar Controller | 30 A, flush mount (included) | 30 A, flush mount (included) | 30 A, flush mount (included) |
| Expansion capability | GP-OVERLANDER-E expansion kits (up to 600 W) | GP-RETREAT-E expansion kit (up to 500 W) | n/a |
| Accessories (included) |
|
||
| Accessories (optional) | Solar expansion kits, adjustable solar mount (ARM-UNI), can be built into a complete solar and inverter system | ||
| Warranty | 25 years (module) / 5 years (controller) | ||
Product Support Resources
MODEL: RETREAT
Learn how to choose a Solar Kit, select an Expansion Kit for the Retreat or use our Go Power! Calculator to size your system.
Included in Kit:
- 100-watt solar panel (GP-PV-100M)
- 30-amp single-bank, Bluetooth® Solar Controller (GP-SB-PWM-30BT)*
- 25′ of solar output cable – RED (#10)
- 25′ of solar output cable – BLACK (#10)
- Mounting hardware (1 x GP-MH-4-KB)
*If you have the GP-PWM-30-UL controller WITHOUT Bluetooth, please click here for the User Manual and Spec Sheet.
Solar Module and Controller
| Solar cell type | Monocrystalline |
|
Output power |
100 W |
|
Rated current |
5.43 A |
|
Rated DC voltage |
18.4 V |
| Open-circuit voltage | 22.6 V |
| Module efficiency | 15.34% |
| Connectivity | Solar Branch Connectors |
| Solar controller | 30 A PWM, multi battery option, 4 stage charging, digital display and flush mount |
| Frame type | Silver / black anodized aluminum frame |
| Certifications | CE |
| Dimensions | 47.09 x 21.46 x 1.38 in / 1196 x 545 x 35 mm |
|
Weight |
17.6 lbs / 8 kg |
|
Warranty |
25 years (module) / 5 years (controller) |
Large Solar Kit Specifications
| OVERLANDER | RETREAT | ECO 80 Watt | |
|---|---|---|---|
| Output power | 200 W | 100 W | 80 W |
| Solar cell | Monocrystalline | Monocrystalline | Polycrystalline |
| Installation | Roof mount | Roof mount | Roof mount |
| Solar Controller | 30 A, flush mount (included) | 30 A, flush mount (included) | 30 A, flush mount (included) |
| Expansion capability | GP-OVERLANDER-E expansion kits (up to 600 W) | GP-RETREAT-E expansion kit (up to 500 W) | n/a |
| Accessories (included) |
|
||
| Accessories (optional) | Solar expansion kits, adjustable solar mount (ARM-UNI), can be built into a complete solar and inverter system | ||
| Warranty | 25 years (module) / 5 years (controller) | ||
